markdown示例#

约 670 个字 270 行代码 4 张图片预计阅读时间 22 分钟

标题(Headings)#

Markdown

# 一级标题

## 二级标题

### 三级标题

#### 四级标题

##### 五级标题

###### 六级标题

文本强调(Emphasis)#

加粗

斜体

加粗加斜体

Markdown

**加粗**

*斜体*

***加粗加斜体***

引用(Blockquotes)#

多萝西跟着她穿过她的城堡中的许多美丽房间。

女巫命令她清洗锅碗瓢盆，扫地，还要不断给火炉加木柴。

嵌套引用

Markdown

> 多萝西跟着她穿过她的城堡中的许多美丽房间。
>
> 女巫命令她清洗锅碗瓢盆，扫地，还要不断给火炉加木柴。
>
>> 嵌套引用

列表(Lists)#

无序列表#

无序列表1
无序列表2
无序列表3

Markdown

- 无序列表1
- 无序列表2
- 无序列表3

有序列表#

有序列表1
有序列表2
有序列表3

Markdown

1. 有序列表1
2. 有序列表2
3. 有序列表3

任务列表#

任务清单1
任务清单2
任务清单3

Markdown

- [x] 任务清单1
- [x] 任务清单2
- [ ] 任务清单3

定义列表#

First Term: This is the definition of the first term.
Second Term: This is one definition of the second term.; This is another definition of the second term.

Markdown

First Term
: This is the definition of the first term.

Second Term
: This is one definition of the second term.
: This is another definition of the second term.

代码(Code)⭐#

局部代码块#

At the command prompt, type nano.

Markdown

At the command prompt, type `nano`.

局部代码块语法高亮#

The range() function is used to generate a sequence of numbers.

Markdown

The `#!python range()` function is used to generate a sequence of numbers.

围栏代码块#

JSON

{
  "firstName": "John",
  "lastName": "Smith",
  "age": 25
}

添加标题#

bubble_sort.py

def bubble_sort(items):
    for i in range(len(items)):
        for j in range(len(items) - 1 - i):
            if items[j] > items[j + 1]:
                items[j], items[j + 1] = items[j + 1], items[j]

添加注解#

YAML

theme:
  features:
    - content.code.annotate # (1)

I'm a code annotation! I can contain code, formatted text, images, ... basically anything that can be written in Markdown.

指定行高亮#

Python

def bubble_sort(items):
    for i in range(len(items)):
        for j in range(len(items) - 1 - i):
            if items[j] > items[j + 1]:
                items[j], items[j + 1] = items[j + 1], items[j]

引入外部文件⭐#

demo.json

{
  "title": "外部json文件",
  "firstName": "John",
  "lastName": "Smith",
  "age": 25
}

水平线(Horizontal Rules)#

Markdown

***

---

链接(Links)#

基本链接#

My favorite search engine is google.

Markdown

My favorite search engine is [google](https://www.google.com).

My favorite search engine is [google](https://www.google.com "鼠标悬停提示").

直接将url转为链接#

https://www.markdownguide.org

fake@example.com

Markdown

<https://www.markdownguide.org>

<fake@example.com>

链接格式化#

I love supporting the EFF.

This is the Markdown Guide.

See the section on code.

Markdown

I love supporting the **[EFF](https://eff.org)**.

This is the *[Markdown Guide](https://www.markdownguide.org)*.

See the section on [`code`](#code).

参考链接#

In a hole in the ground there lived a hobbit. Not a nasty, dirty, wet hole, filled with the ends of worms and an oozy smell, nor yet a dry, bare, sandy hole with nothing in it to sit down on or to eat: it was a hobbit-hole, and that means comfort.

Markdown

In a hole in the ground there lived a hobbit. Not a nasty, dirty, wet hole, filled with the ends
of worms and an oozy smell, nor yet a dry, bare, sandy hole with nothing in it to sit down on or to
eat: it was a [hobbit-hole][1], and that means comfort.

[1]: <https://en.wikipedia.org/wiki/Hobbit#Lifestyle> "Hobbit lifestyles"

图片(Images)#

基本图片#

Markdown

![image](img/demo.jpg)

material-带标题的图片#

Markdown

<figure markdown="span">
  ![Image title](img/demo.jpg)
  <figcaption>Image caption</figcaption>
</figure>

表格(Tables)#

简单表格#

First Header	Second Header	Third Header
Content Cell	Content Cell	Content Cell
Content Cell	Content Cell	Content Cell

Markdown

| First Header | Second Header | Third Header |
|--------------|---------------|--------------|
| Content Cell | Content Cell  | Content Cell |
| Content Cell | Content Cell  | Content Cell |

内容对其(Alignment)#

First Header	Second Header	Third Header
左对齐	居中对齐	右对齐
x	x	x

Markdown

| First Header | Second Header | Third Header |
|:-------------|:-------------:|-------------:|
| 左对齐          |     居中对齐      |          右对齐 |
| x            |       x       |            x |

material-警告(Admonitions)#

mkdocs.yml配置#

YAML

markdown_extensions:
  - admonition
  - pymdownx.details
  - pymdownx.superfences

基本使用#

Note

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor massa, nec semper lorem quam in massa.

Markdown

!!! note

    Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod
    nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor
    massa, nec semper lorem quam in massa.

自定义标题#

Phasellus posuere in sem ut cursus

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor massa, nec semper lorem quam in massa.

Markdown

!!! note "Phasellus posuere in sem ut cursus"

    Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod
    nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor
    massa, nec semper lorem quam in massa.

隐藏标题#

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor massa, nec semper lorem quam in massa.

Markdown

!!! note ""

    Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod
    nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor
    massa, nec semper lorem quam in massa.

可折叠#

Note

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor massa, nec semper lorem quam in massa.

Markdown

??? note

    Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nulla et euismod
    nulla. Curabitur feugiat, tortor non consequat finibus, justo purus auctor
    massa, nec semper lorem quam in massa.

各种类型#

Note

Abstract

Info

Tip

Success

Question

Warning

Failure

Danger

Bug

Example

Quote

material-注解(Annotations)#

mkdocs.yml配置#

YAML

markdown_extensions:
  - attr_list
  - md_in_html
  - pymdownx.superfences

注解示例#

Lorem ipsum dolor sit amet, (1) consectetur adipiscing elit.

I'm an annotation!

Markdown

Lorem ipsum dolor sit amet, (1) consectetur adipiscing elit.
{ .annotate }

1. I'm an annotation!

material-按钮(Buttons)#

mkdocs.yml配置#

YAML

markdown_extensions:
  - attr_list

示例#

Subscribe to our newsletter

Send

Markdown

[Subscribe to our newsletter](#){ .md-button }

[Subscribe to our newsletter](#){ .md-button .md-button--primary }

[Send :fontawesome-solid-paper-plane:](#){ .md-button }

material-内容选项卡(Content Tabs)#

CC++

C

#include <stdio.h>

int main(void) {
  printf("Hello world!\n");
  return 0;
}

C++

#include <iostream>

int main(void) {
  std::cout << "Hello world!" << std::endl;
  return 0;
}

Markdown

=== "C"

    ``` c
    #include <stdio.h>

    int main(void) {
      printf("Hello world!\n");
      return 0;
    }
    ```

=== "C++"

    ``` c++
    #include <iostream>

    int main(void) {
      std::cout << "Hello world!" << std::endl;
      return 0;
    }
    ```

material-图表(Diagrams)#

流程图#

graph LR
  A[Start] --> B{Error?};
  B -->|Yes| C[Hmm...];
  C --> D[Debug];
  D --> B;
  B ---->|No| E[Yay!];

mermaid

graph LR
  A[Start] --> B{Error?};
  B -->|Yes| C[Hmm...];
  C --> D[Debug];
  D --> B;
  B ---->|No| E[Yay!];

时序图#

sequenceDiagram
  autonumber
  Alice->>John: Hello John, how are you?
  loop Healthcheck
      John->>John: Fight against hypochondria
  end
  Note right of John: Rational thoughts!
  John-->>Alice: Great!
  John->>Bob: How about you?
  Bob-->>John: Jolly good!

Markdown

sequenceDiagram
  autonumber
  Alice->>John: Hello John, how are you?
  loop Healthcheck
      John->>John: Fight against hypochondria
  end
  Note right of John: Rational thoughts!
  John-->>Alice: Great!
  John->>Bob: How about you?
  Bob-->>John: Jolly good!

状态图#

stateDiagram-v2
  state fork_state <<fork>>
    [*] --> fork_state
    fork_state --> State2
    fork_state --> State3

    state join_state <<join>>
    State2 --> join_state
    State3 --> join_state
    join_state --> State4
    State4 --> [*]

Markdown

stateDiagram-v2
  state fork_state <<fork>>
    [*] --> fork_state
    fork_state --> State2
    fork_state --> State3

    state join_state <<join>>
    State2 --> join_state
    State3 --> join_state
    join_state --> State4
    State4 --> [*]

类图#

classDiagram
  Person <|-- Student
  Person <|-- Professor
  Person : +String name
  Person : +String phoneNumber
  Person : +String emailAddress
  Person: +purchaseParkingPass()
  Address "1" <-- "0..1" Person:lives at
  class Student{
    +int studentNumber
    +int averageMark
    +isEligibleToEnrol()
    +getSeminarsTaken()
  }
  class Professor{
    +int salary
  }
  class Address{
    +String street
    +String city
    +String state
    +int postalCode
    +String country
    -validate()
    +outputAsLabel()
  }

Markdown

classDiagram
  Person <|-- Student
  Person <|-- Professor
  Person : +String name
  Person : +String phoneNumber
  Person : +String emailAddress
  Person: +purchaseParkingPass()
  Address "1" <-- "0..1" Person:lives at
  class Student{
    +int studentNumber
    +int averageMark
    +isEligibleToEnrol()
    +getSeminarsTaken()
  }
  class Professor{
    +int salary
  }
  class Address{
    +String street
    +String city
    +String state
    +int postalCode
    +String country
    -validate()
    +outputAsLabel()
  }

实体关系图#

erDiagram
  CUSTOMER ||--o{ ORDER : places
  ORDER ||--|{ LINE-ITEM : contains
  LINE-ITEM {
    string name
    int pricePerUnit
  }
  CUSTOMER }|..|{ DELIVERY-ADDRESS : uses

Markdown

erDiagram
  CUSTOMER ||--o{ ORDER : places
  ORDER ||--|{ LINE-ITEM : contains
  LINE-ITEM {
    string name
    int pricePerUnit
  }
  CUSTOMER }|..|{ DELIVERY-ADDRESS : uses
